Hydraulic brake hose
Application: Hydraulic system of all kinds of automobile and motorcycle to transfer the hydraulic power.
- Commodity name： Hydraulic brake hose
- Commodity ID： cp001
- Description
-
Product Introduction
Application: Hydraulic system of all kinds of automobile and motorcycle to transfer the hydraulic power.
Commodity Hydraulic brake hose Standards SAE J1401，FMVS 106 Quality control CQC16-491284-2018 Material Tube: EPDM, perfectly resist oil, heat and permeation of water
Reinforcement: high strength polyester fiber treated by special resin;
Middle layer: using viscosity-strengthen middle rubber between reinforcement to provide high dynamic capability
Cover: EPDM, perfectly resist heat and ozoneBrake fluid DOT3, DOT4 Normal size 3.2mm x 10.5mm(1/8”)
3.2mm x 12.5mm(1/8”)
4.8mm x 12.5mm(3/16”)Special size 3.0mm x 11.0mm, 3.0mm x 11.5mm，3.5mm x 10.5mm etc Features Low volumetric expansion;
Ozone resistance;
Low and high temperature toughness range -55℃ - 125℃;
Exclusive whip performance;
High tensile performance;
Burst pressure≥60Mpa;
Excellent moisture resistance;
Stable, safe and reliable brake performance.Length/piece 10 - 80m Guaranteed 100000kms or 5 years Product Size
Size I.D O.D Inch Length Unit packing Package Normal 3.2mm 10.5mm 1/8” 10-80m/pc 200m/roll carton，pallet 3.2mm 12.5mm 1/8” 10-80m/pc 200m/roll carton，pallet 4.8mm 12.5mm 3/16” 10-80m/pc 200m/roll carton，pallet Special 3.0mm 11.0mm 10-80m/pc 200m/roll carton，pallet 3.0mm 11.5mm 10-80m/pc 200m/roll carton，pallet 3.5mm 10.5mm 10-80m/pc 200m/roll carton，pallet
We Are the Manufacturer
At Junze, we are committed to developing industry-leading, innovative products. We meet this goal by constantly striving to better understand what the installer wants and prefers, then bring it to life. all manufacturing processes from raw materials to final assembly are produced in-house, giving us complete control over the quality and consistency of our products.
